High Quality Cheap Price Rubber Conveyor Belt 4 Ply 800mm Belt Flame Resistant Ep Conveyor Belt
These belts are highly effective in moving bulk materials such as lumps, granules, and powders, as well as packaged items, making them perfect for applications that require long-distance and high-capacity transportation.
- Description
- Specifications
- Applications
- Advantages
- FAQ
- Recommended Products
Description
EP conveyor belts, also known as polyester conveyor belts, are essential components in industrial material handling systems. They are specifically designed to handle heavy loads, cover long distances, and operate under challenging conditions. These belts are constructed with a high-strength polyester canvas (EP) core, which is stabilized by precisely woven polyester fibers in both the warp and weft directions. The outer layer is made of high-quality rubber, providing excellent resistance to wear and impact, thereby ensuring both a high load capacity and a prolonged service life.
We offer flexible specifications and customization options, with a range of standard widths from 300mm to 6000mm, thicknesses between 4mm and 20mm, and strength grades from EP100 to EP400, which correspond to fabric tensile strength per layer of 100N/mm to 400N/mm. This ensures suitability for all light, medium, and heavy-duty applications. From the selection of raw materials to the inspection of finished products, we rigorously comply with international standards like ISO and GB/T 7984. Each meter of belt is subjected to tests for tensile strength, abrasion resistance, and temperature endurance to guarantee dependable performance upon delivery. Opting for EP conveyor belts means selecting an efficient, safe, and cost-effective solution for material handling!
Specifications
| Cover Rubber grade | 8MPA,10MPA,12MPA,15MPA 18MPA,20MPA,24MPA,26MPA | |
| Top+Bottom thickness | 3+1.5,4+2,4+1.5,4+3 | 3/16"+1/16",1/4"+1/16" |
| Belt thickness | 3mm,4mm,5mm,6mm,7mm,8mm,9mm,10mm,12mm,15mm,20mm,25mm | |
| Belt length | 10m,20m,50m,100m,200m,250m,300m,500m | |
| Belt edge type | moulded(sealed) edge or cut edge | |
| Belt width (mm) | 500,600,650,700,800,1000,12001400,1500,1800,2000,2200,2500 | 18",20",24",30",36",40",42"48",60",72",78",86",94" |
| Tensile strength | EP315/3,EP400/3,EP500/3,EP600/3 EP400/4,EP500/4,EP600/4EP500/5,EP1000/5,EP1250/5 EP600/6,EP1200/6 | |
| Specifications and technical parameters of polyester multi-layer conveyor belts | |||||||
| Fabric Type | Fabric structure | Fabric specs | Ply thickness (mm/p) | Strength series (N/mm) | |||
| Warp | Weft | 2layer | 3layer | 4layer | |||
| Polyester (EP) | Polyester | Nylon | EP-100 | 1.00 | 200 | 300 | 400 |
| EP-125 | 1.05 | 250 | 375 | 500 | |||
| EP-150 | 1.10 | 300 | 450 | 600 | |||
| EP-170 | 1.10 | 340 | 510 | 680 | |||
| EP-200 | 1.20 | 400 | 600 | 800 | |||
| Core material | Adhesion strength | ||
| Between fabric layers (N/mm) | Between covering layer and cloth layer (N/mm) | ||
| Thickness of Layer ≤1.5mm | Thickness of Cover ≥1.5mm | ||
| polyester canvas | ≥5 | ≥4.5 | ≥5 |
| Extended performance | |||
| Full thickness longitudinal tensile elongation at break | Full thickness longitudinal reference force elongation | ||
| ≥10% | ≤4% | ||
| Cover Grade | Tensile Strength≥ | Elongation at break≥ | Wear loss≤ | Tensile Strength and Elongation at Break after Aging |
| Mpa | % | mm3 | % | |
| H | 24 | 450 | 120 | -25~+25 |
| D | 18 | 400 | 100 | -25~+25 |
| L | 15 | 350 | 200 | -25~+25 |
Applications
Polyester conveyor belts(EP conveyor belts)are widely used in coal,mining ports,metallurgy,electric power,chemical industry and other fields to transport materials.
Advantages
1.High strength,thin belt body,light weight
2.Use EP dipped canvas as the skeleton Material
3.The belt body is soft,has good troughing properties,and has good elasticity.
4.Impact resistance,wear resistance,and corrosion resistance.
5.Adaptable to larger load capacity,faster speed,and medium and long-distance material transportation.
6.Smooth operation and no deviation.
FAQ
1. What are the advantages of your conveyor belts compared to other brands?
1:Targeted Design: Based on years of field experience in Saudi Arabia, we engineer our belt’s ply count and rubber grade to precisely match your application.
2:Localized Service: We provide "hands-on" technical support throughout the entire process—from selection and installation to subsequent optimization—ensuring you achieve optimal results, not just receive a belt.
3:Cost Advantage: We have our own factory, eliminating middlemen. This allows us to offer more competitive prices while guaranteeing quality. We deliver long-term, stable operation, not just a product.
2. Is your conveyor belt under warranty? How long is the warranty period?
We provide clear and fair warranty terms to ensure mutual understanding:
1:A one-year warranty is provided under normal operating conditions (covering issues like delamination and core breakage).
2:Normal wear and tear of the top and bottom cover rubber is excluded.
3:Punctures and cuts caused by external factors are not covered.
Our Hot Vulcanized Jointing Service is covered by a separate one-year warranty. (This warranty excludes issues resulting from mechanical damage, human error, or improper maintenance.)
3. How is the belt splicing handled? Do you provide on-site service?
The splice is the "lifeline" of any conveyor belt, and we treat it with utmost importance. We offer:
1:Professional Hot Vulcanized Splicing Service: Our engineer team uses professional equipment to ensure a splice efficiency of over 90%, achieving a strength nearly equal to the belt itself.
2:On-site Guidance & Execution: We don't just advise; we can dispatch our engineers to your site to ensure the splice is done correctly the first time, preventing the risk of future breakages during operation.
4. What is the service life of the belt?
The service life of a conveyor belt depends on various factors, including material abrasiveness, load capacity, operating environment, and maintenance standards.
Based on our experience serving similar clients in Saudi Arabia, under normal conditions and with proper maintenance, our products are typically designed to last 1-2 years.
Most importantly, through accurate selection and regular maintenance tracking services, we proactively help you avoid abnormal wear, striving to maximize the product's service life and thereby reduce your cost per ton conveyed.
5. What is your response if we encounter a problem with the belt?
We have established a localized rapid response mechanism in Saudi Arabia:
1:Technical Consultation: For any operational queries, we provide remote technical support within 24 hours.
2:Emergency Breakdowns: For critical issues causing downtime, we commit to providing a clear on-site support arrival time and establishing an emergency communication channel.
3:Spare Parts Support: We maintain a local spare parts stock in Saudi Arabia to ensure the rapid supply of critical components.
Our goal is to become your long-term partner, not just a one-time supplier. Therefore, resolving issues quickly is in our mutual interest.
